| Maximum Load Capacity | : | 130 ton |
|---|---|---|
| Boom Length | : | 52.2 Meters |
| Dimensions | : | 3.3x3x15 Meters |
| Operating Hours | : | 943 Hours |
| Types of Boom | : | Telescopic |
| Main Counter Weight | : | Yes |
| Configuration | : | - SENNEBOGEN MAXCAB - cab with sliding door - Skylight - Wiper and washer system for front and roof window - Heating- Climateautomatic with central control elements - SENNEBOGEN control & diagnostic system SENCON - Lighting system: 2 lights integrated in the front side of the cab roof 1 LED headlight (24V/50W) on the upper carriage at the right side - Camera system - base package with 2 cameras includes 1 colour monitor 7'', monitor with 4-way split, up to 4 cameras expandable, 2 cameras with 115° field viewing angle for rear view camera and right side of the machine - Counterweight 35.3 metric tons - Counterweight lowering system, hydraulically - Tool kit Hydraulically extendable undercarriage T119/ 540 with B8b crawlers, crawler length 8,050mm, track gauge min. 3,050mm, max. 5,400mm very easy removable crawlers, hydraulic lifting attachment with 4 hydraulic lift cylinders mounted at the undercarriage for loading the machine onto trailers. Maintenance-free B8b track (74 track shoes) with 900mm flat track shoes, welded type for T119/540 Two-stage track motors for higher travel speed, B8b crawlers Cab adjustment for SENNEBOGEN MAXCAB with 20 degrees rear tilt capability for improved overhead vision and ergonomic posture SENNEBOGEN MAXCAB operator's cab with sliding door incl. sliding window, resiliently mounted, tinted safety glass, tiltable front window, skylight, wiper/washer system for front window and skylight, Radio in preparation with aerial and loudspeakers, 2 lights integrated in the front of the roof, automatic air condition with fresh air and circulation air filters. Air suspended operator's seat with lumbar support, seat heating and headrest for driver´s seat 2 inch seat belt - standard Sun protection for skylight, only for MAXCAB Skylight of bullet proof glass, fixed glazing, for MAXCAB operator's cab Radio with USB port, MP3 and Bluetooth Positioning swing break via foot pedal indication for winch movement (winch 1 and 2, if installed) via vibration at the left and right joystick 1 pc. hand fire extinguisher, type PD6 Grated step on side of cab (removable) Grated step in front of cab Catwalk on both sides (left and right) of the upper structure (without handrail), removable (not foldable), 500mm wide Width of upper structure with mounted catwalks 4,145mm Hand rail at the upper structure, foldable, 1100mm high Standard lubricants for operation range between -20°C and +40°C, for diesel machines Information: hydraulic oil type needs to be defined separately Warning and Safety signs according to ISO standard (International Organization for Standardization) Hydraulic oil Shell Tellus S2 VA 46 IMPORTANT HINT regarding hydraulic-/biodegradable oil: Basing on the big variety of hydraulic-/biodegradable oils available on the market, it is not possible for SENNEBOGEN to test all types and therefore standard oils are defined. If the customer provides other oil types or requests filling with other oil types, SENNEBOGEN does not give any warranty for direct and/or indirect damages at the machine, based on the filling of customer specific oil! SENNEBOGEN Hydro-Clean: Hydraulic micro filter system with water absorption contamination indicator (higher oil purity and extended oil service life), equipment recommended especially when biodegradable oil is used Pinion lubrication for slewing gear with lubrication pump, operated from cab, with special lubricant and pinion lubrication system automatic central lubrication for telescopic crane: - pivot point main boom - pivot point luffing cylinder - slewing ring path Pin boom, six-sections, length from 12.3m up to 52.2m hydraulically extendable/ retractable Crane winch, line pull 120kN (on the 7th layer) with precision hoist control, rope diameter 26mm, low-maintenance, with rope tensioning roller; including safety device for the last 3 layers 2nd crane winch, line pull 120kN with precision hoist control, low-maintenance, rope diameter 26mm, with rope tensioning roller, including safety device for the last 3 layers, with hoisting rope - diameter 26mm, length 210m with pocket lock, without hook 1 Hoisting rope, diameter 26mm, length 210m with pocket lock 1 wedge socket with pin for hoisting rope, diameter 26mm, loose attached at machine. 80t SH, 26mm rope, 3 sheaves, Spec.-nr. 080.26.3.1000, approx.1000kg Runner 12t incl. 15t single hook for 26mm rope, 0 sheaves Jib, length 8m, mountable to the telescopic boom, swinging away to the side / telescopic boom, offset 0° / 20° / 40°, hoist limit switch, without load hook, incl. stowage bracket ATTENTION: Load hook has to be ordered seperately as required! Extension of the jib to a total length of 15m, length 7m, mountable to 8m jib, offset 0° / 20° / 40°, hoist limit switch, without load hook Electronic load moment indicator (LMI) incl. load weight indication via the electronic load moment indicator, incl. program and event recorder, recording of information from the LMI system. Crane Test and LMI program for following configurations in combination with crawler undercarriage T119/540: - ctw 35.3t; track gauge 5.4m and 4.2m - ctw 21.3t; track gauge 5.4m, 4.2m - ctw 0.0t; track gauge 5.4m, 4.2m and 3.05m - 8m foldable jib; ctw 35.3t; track gauge 5.4m - 7m extension for foldable jib; ctw 35.3t; track gauge 5.4m - runner 12t Standard paintwork: body, boom RAL 6018 green, cab RAL 7038 grey, undercarriage, upper structure, winches, luffing cylinder, jib and runner RAL 7022 grey, internal boom sections matt black Operations and maintenance manual in duplicate, in German or English language Spare parts catalogue online available - 8 languages (German, English, Spanish, French, Italian, Portuguese, Turkish, Russian) - Continuous updating NOTE: The catalogue is also provided for download as a pdf-file. SENtrack telematics system including data connection for 3 years from initial putting into operation. Standard SIM Range of functions: - Online access to user interface - Geographical tracking - Geofencing, movement supervision, operating time supervision - Notification feature (mail and mobile) in case of movement or faults - Maintenance reminder and confirmation - Transmission of error codes (DTC) and warning lights - AEMP interface (ISO 15143) - Printable statistic report for consumption, occupancy rate and operation time Covered states: Member states European Union, Albania, Algeria, Anguilla, Antigua and Barbuda, Argentina, Armenia, Australia, Azerbaijan, Barbados, Belarus, Bosnia and Herzegovina, British Virgin Islands, Cambodia, Canada, Cayman Islands, Chile, Hong Kong, Colombia, Dominica, Egypt, El Salvador, Equatorial Guinea, Faroe Islands, Georgia, Gibraltar, Greenland, Grenada, Guernsey, Guyana, Iceland, India, Indonesia, Isle of Man, Israel, Japan, Jersey, Jordan, Kazakhstan, Kyrgyzstan, Liechtenstein, Malaysia, Mexiko, Monaco, Mongolia, Montenegro, Montserrat, Morocco, New Zealand, Norway, Oman, Paraguay, Peru, Philippines, Republic of Korea, Republic of Moldova, Russian Federation, Saint Kitts and Nevis, Saint Lucia, Saint Vincent and the Grenadines, Serbia, Singapore, South Africa, Sri Lanka, State of Palestine, Switzerland, Taiwan, Thailand, The former Yugoslav Republic of Macedonia, United Kingdom of Great Britain and Northern Ireland, Tunisia, Turkey, Turks and Caicos Islands, Ukraine, United Arab Emirates, USA, Vietnam |
| Engine Detail | : | - CUMMINS Engine B 6.7 FR95885, 168kW/2200 rpm, operating point 186kW/2000 rpm, exhaust emissions according to to Regulation (EU) 2016/1628 Stage V/US EPA Tier 4 final, watercooled including electrically heated water separator with fuel prefilter 24V - Automatic idle speed stop for diesel engine - Eco-mode for diesel engine |
| Usage | : | The Sennebogen 6133 E is a 130-ton crawler telescopic crane. It combines the off-road capability of crawler tracks with the flexibility of an extending telescopic boom. Key Applications Rough Terrain Operations: The crawler tracks provide excellent stability on muddy or uneven ground (e.g., bridge or highway construction) where wheeled cranes would get stuck. "Pick & Carry": Unlike standard mobile cranes that must be stabilized on outriggers, this crane can lift heavy materials and drive across the job site with the load still suspended on the hook. Precast & Steel Assembly: The quick-extending boom is ideal for reaching high elevations to precisely position heavy concrete elements or steel beams. Confined Spaces: Because the boom telescopes in and out, it requires much less setup area than traditional lattice boom cranes (which must be assembled on the ground). This makes it perfect for tight industrial or urban sites. Wind Farm Support: It is frequently used as an auxiliary crane to unload huge turbine components from trucks and to assist in setting up the massive main cranes. |
|---|---|---|
| Certification | : |
